7 Best Clamp Meters in India: How to Select a Good Clamp Meter
A clamp meter is a must-have instrument for electricians and technicians, and if it is said to be the best clamp meter, it must be precise, dependable, and efficient.
Many manufacturers offer clamp meters in India, making it difficult to select the ideal one for your needs.
A clamp meter and a reliable multimeter are essential tools for any good electrical expert working in the high-current measuring or testing sector. We already have a fantastic article that compares a multimeter to a clamp meter.
There are several clamp meters on the market, and selecting the proper one might be difficult.
This post will guide you through the top clamp meters available in India as well as their characteristics.
We hand-picked these meters based on our previous experience with them, and we have no affiliation with these companies.
Best Clamp Meter in India
Editor’s Choice: Kaiweets HT206D
Value for Money: Kaiweets HT208D
Best Professional: Fluke-325
Best Compact: Fluke 362
Best Innovative : Plusivo CL 101C
Best Beginner Friendly: Meco 27 and HTC CM-2030
1. Kaiweets Digital Clamp Meter HT206D
The Kaiweets Digital Clamp Meter HT206D is a highly accurate and versatile true RMS clamp multimeter for electricians and technicians who need to measure AC/DC voltage and current, resistance, capacitance, frequency, or duty cycle, as well as perform diode, temperature, and continuity tests.
It can measure a maximum current of 600 A AC/DC. Because of its extensive capabilities and user-friendly design, it is an economical and dependable true RMS measuring choice that has gained appeal among labs, companies, and households.
Its low input impedance aids in the prevention of false readings caused by ghost voltage. In addition, while measuring motors and transformers, a low-pass filter (LPF) improves the precise measurement of variable-frequency driving signals.
Its non-contact voltage (NCV) detector checks electrical status by identifying electromagnetic field strength without touching any wires.
This clamp meter features a big, two-colour backlit display that glows red when the voltage or current under measurement exceeds 80 volts or 3 A.
It also features a flashlight, which is particularly useful for seeing the area under test in low-light conditions.
Its temperature-measuring feature allows it to measure the temperature of liquids or air conditioner ports using the included K-type thermocouple.
Other useful features of this clamp meter include a low battery indicator and auto shut-off.
Kaiweets Digital Clamp Meter HT206D meets IEC 61010-1 safety standards and features CAT III 600V double insulation. Furthermore, the manufacturer provides a 3-year warranty for this device.
2.Kaiweets HT208D Inrush Clamp Meter
The Kaiweets HT208D Inrush Clamp Meter is another high-quality clamp meter that can measure currents up to 1000 A.
It is comparable to the Kaiweets HT206D, but it has more features, such as a measurement current capacity of up to 1000 A and a voltage measurement capacity of up to 1000 V, and it can efficiently monitor inrush current.
It can also measure the true-RMS value and up to 1000 V AC/DC voltage, frequency, duty cycle, resistance, capacitance, diode, continuity, and temperature. So it is also the best clamp multimeter.
This meter, like the previous type stated above, may be used as a professional clamp meter in labs, industries, and at home.
As previously stated, another distinguishing characteristic of this clamp meter is its ability to detect inrush current in motor circuits, which is extremely useful in resolving motor starting issues.
It also has a built-in non-contact voltage (NCV) detector, which can swiftly and simply assess the existence of an electrical field without seeing or touching it.
For simple viewing, a handy LED flashlight illuminates a poorly lit testing or measuring area.
Variable Frequency Drive Filtering (VFD) and Low Input Impedance (LoZ) modes on the clamp meter can deliver more accurate readings.
Because it complies with IEC 61010-1, CAT IV 600V, and CAT III 1000V, this clamp meter provides dependable safety protection.
Because it is built of high-quality materials and has double insulation, it provides greater protection against electrical shock.
3. Fluke FLUKE-325 Clamp Meter
The Fluke 325 True-RMS Clamp Meter is a dependable and adaptable electrical troubleshooting tool for commercial and household applications.
It has a slim form for convenient transport and usage, as well as a big display for effective troubleshooting.
The 325 monitors DC, DC voltage, temperature, and frequency in addition to true-RMS AC and voltage on non-linear loads.
The 325 provides a powerful mix of measuring tasks in an instrument that is dependable, simple to use, and reasonably priced.
It measures AC/DC up to 400 A using the jaw, AC/DC voltage up to 600 V using test leads, frequency from 5 Hz to 500 Hz, resistance to 40 kΩ, and temperature from -10 °C to 400 °C with the integrated K-type thermocouple.
To provide a safe working environment, this clamp meter is paired with the CAT III 600 V and CAT IV 300 V safety standards.
Its Min/Max feature assists in the recording of crucial measurable data.
From the date of purchase, this clamp meter is covered by a two-year warranty against manufacturing defects.
This is a wonderful alternative if you need a professional clamp meter that can measure current up to 400 A AC/DC.
4. Fluke 362, 200A AC/DC Clamp Meter
The Fluke 362 Clamp Meter is small enough to fit in your pocket. The compact 18 mm triangle jaw offers entry into confined spaces that other clamp meters cannot, while still offering the precision you expect from a Fluke instrument.
This long-lasting clamp meter is essential for basic maintenance clamp readings and testing. It can measure up to 200 A AC/DC, a 600 V AC/DC voltage range, a 3000 resistance range, and detect continuity.
It also contains a data hold capability to keep the value shown on the screen. This Fluke clamp meter features a CAT III 600 V safety certification, which offers a high level of electrical shock protection.
It has a big and easy-to-read LCD. Overall, it is a compact clamp meter that is simple to operate.
The new 362 Fluke Clamp Meter is intended to fit conveniently in your pocket because it is lightweight, thin, and small.
Its small 18-mm triangular jaw offers entry into confined spaces that other clamp meters cannot, while still offering the precision you expect from a Fluke product.
This long-lasting clamp meter is essential for simple maintenance clamp readings.
If you need a decent, compact, and simple-to-use professional clamp meter for AC/DC measurements up to 200 A, this is a solid option.
5. Plusivo CL 101C Clamp Meter
This digital clamp meter can detect both AC and DC voltages. Also, it can measure alternating current and direct current up to 600 amps.
It can also measure temperature, AC and DC voltage, capacitance, continuity, resistance, diode testing, low impedance voltage measurement, and frequency.
The NCV feature in this meter allows you to check electrical potential without touching any wires and determine whether the conductor being tested has a voltage of more than 90 V AC.
Three AAA batteries are required to power this clamp meter. This instrument has several functions, including an LCD, low battery detection, overload protection, and automatic power down after fifteen minutes of inactivity, among others.
This digital clamp meter also includes test clips, DuPont wire probes, crocodile clips, mini crocodile cable, thermocouples, a mini wire stripping tool, mini screwdrivers, electrical tape, and a downloadable user manual e-book.
The manufacturer backs the Plusivo Clampmeter with a 30-day money-back guarantee and lifelong customer support to ensure customer satisfaction.
6. Meco 27-auto Digital Clamp Meter
The Meco 27-Auto Digital Clamp Meter is a straightforward and stylish digital clamp meter.
It maintains its standing as a product from a respected company in measuring instruments by producing a quality product with a high build quality.
The Meco MC 27T measures 400 A AC and has an auto-ranging function. Its 3 ½-digit, 2000-count LCD device vividly shows measured units in suitable font size.
It should be noted that this clamp meter cannot be used to measure DC (current). Other parameters that may be measured include AC voltage up to 400 volts AC/DC, resistance, DC voltage, and temperature.
Other useful features of the Meco 27-auto Digital Clamp Meter include data hold, Audible Continuity, and Diode Test.
This is a low-cost clamp meter, so don’t expect it to have a great degree of measurement precision.
However, it is a nice clamp meter for novices, and keep in mind that it cannot measure DC (current).
7. HTC Instrument CM-2030 Digital AC Clamp Meter
It is a clamp meter for measuring direct current (DC). It is capable of measuring up to 1000 A.C. It cannot be used to monitor DC (current).
Furthermore, this HTC clamp meter may be used to measure AC/DC voltage and resistance. There are additional provisions for continuity and no-voltage contact (NCV) testing.
It includes a big 3 ½ LCD panel with a backlight for displaying measured values.
This clamp meter provides a reasonably accurate, true RMS value measurement.
A built-in lamp is included with this instrument for optimal sight of the testing area in low-light locations. This is also a budget-friendly clamp meter for beginners.
Things to Consider While Selecting a Good Clamp Meter
As we know, Clamp meters measure current in a circuit by clamping a jaw or clamp around a conductor and showing the result on a digital screen.
Many things must be considered while picking a decent clamp meter for your job. In this article, we will go over these considerations as well as how to choose a decent clamp meter in India.
1. Determine the Purpose
The first step in selecting a quality clamp meter is determining the meter’s function for which you want to use it.
Because various clamp meters are intended for certain tasks. Some meters, for example, are intended for industrial usage, while others are intended for residential or office use.
Determine the jobs you will conduct with the clamp meter and choose a meter that is appropriate for those duties.
2. Accuracy
One of the most significant elements to examine is the clamp meter’s accuracy.
Choose a clamp meter that has a good accuracy rating. When using a clamp meter for professional purposes, it should be highly accurate.
Most clamp meters have an accuracy rating of +/-1%; however, some low-cost devices may have a greater or lower value.
Check that the meter’s precision is appropriate for the sort of work you’ll be undertaking.
3. Range of Measurement
Another crucial element to consider is the clamp meter’s range. The meter’s range should be appropriate for the sort of task you’ll be taking on.
If you’re going to be working in high currents, you’ll need a meter with a wide range.
Check if the meter’s range is sufficient for your needs. The clamp meter’s price is nearly proportionate to its capacity to measure high ranges.
4. Build Quality
The clamp meter’s build quality is also a significant consideration. Look for a meter that is long-lasting and well-made.
The clamp should be built of high-quality materials that can survive repeated usage.
5. Brand and Price
Finally, examine the clamp meter’s brand and pricing. Choose a trustworthy company that is well-known for creating excellent measuring instruments.
While pricing should not be the only aspect of your selection, it is an essential one. Look for a meter that is reasonably priced for its value.
6. Support
Always choose a clamp meter that comes with a well-written user manual and support.
You will receive all of these things if you choose a decent brand, such as Fluke or Kaiweets. Furthermore, such renowned brands will provide excellent after-sales service.
7. Additional Features
Some clamp meters provide extra capabilities that might be beneficial in specific situations. For example, they may include a backlit display, which is beneficial while working in low-light circumstances.
Others may include a data hold capability that allows you to freeze the screen reading. Look for a meter that has extra functions that are appropriate for your needs, such as NCV, auto-ranging, auto-power off, and so on.
Finally, choosing a decent clamp meter necessitates a careful evaluation of its accuracy, range, extra features, build quality, brand, and pricing.
Taking these criteria into consideration, you can choose a meter that is appropriate for your needs and gives precise and dependable readings.
Summary
The selection of the proper clamp meter is critical, yet the market is overrun with alternatives. It is just as crucial as choosing the best multimeter for your needs.
The clamp meters described above are the best on the Indian market and offer features that set them apart. It is critical to consider your needs, budget, and the sort of job you conduct when selecting a clamp meter.
If you’re a professional electrician or technician, a high-end clamp meter like the Kaiweets HT208D or FLUKE-325 is recommended. These powerful meters are great for solving difficult electrical issues.
They are also long-lasting and dependable, which is vital for professionals who use them regularly.
If you’re still on a tight budget but want a clamp meter with all the features, the Kaiweets Digital Clamp Meter HT206D is our top pick for all types of users.
Fluke 362 is a professional clamp meter with a low current rating that is also compact.
The Plusivo Digital Clamp Meter T-RMS is a flexible meter that can measure a variety of parameters, making it a good choice for people looking for a simple clamp meter.
The Meco 27 and HTC Instrument CM-2030 are outstanding, affordable solutions.
They provide the fundamental functions required for monitoring voltage and current with some accuracy and are reasonably priced without sacrificing quality.
Finally, the ideal clamp meter for you is determined by your unique demands and budget. It is critical to select a meter that is precise, dependable, and efficient, as well as having features that are appropriate for the sort of job you do.
Purchasing a high-quality clamp meter is a sensible investment for professionals who use it regularly since it will last longer and provide more advanced capabilities to ease complex electrical challenges.
Frequently Asked Questions
Not all clamp meters can measure both alternating current (AC) and direct current (DC). Check the clamp meter’s specs to confirm it handles the type of current you need to measure. Some clamp meters are solely designed to detect AC, whereas others can measure both AC and DC.
When used properly, clamp meters are typically safe to use. However, it is critical to follow the manufacturer’s safety precautions and standards. Check that the clamp meter is rated appropriately for the electrical readings you are taking. When using a clamp meter, wear adequate personal protective equipment (PPE) and prevent contact with live conductors.
While clamp meters are primarily intended for current measurements, different models also have extra features. You may be able to measure voltage, resistance, capacitance, frequency, temperature, and other characteristics depending on the clamp meter model. It is critical to understand the clamp meter’s specifications to assess its capability for various electrical measurements.
There are several brands of clamp meters available on the market. The top clampmeter models are made by Fluke, Kaiweets, Meco, HTC, and Plusivo.
We may anticipate one per cent accuracy from high-quality clamp meters. However, with low-quality clamp meter types, it may reach 10%.
Clamp meters are categorized into two different types based on their operating principles. The first is a current transformer clamp meter, which can only measure alternating current. The second kind is a hall effect clamp meter, which can measure both alternating current and direct current.
